Turbo Air Blower

The air suspension blower is a new concept blower. It adopts three core high-end technologies: "ultra-high-speed direct-connected motor", "air suspension bearing" and "high-precision single-stage centrifugal impeller", creating a new era of high-efficiency, high-performance, low-noise and low-energy consumption fans.

The working principle of the air suspension blower is that the blades in the impeller assembly use the rotation of the motor to form a spiral wind, and the tangential wind flow of the blades causes the air to produce pressure pulsation, thereby extracting the air out of the exhaust chamber. Its suspended low-pressure turbulence is caused by the simultaneous existence of the motor and the impeller assembly, which can effectively discharge the airflow outward to form an air suspension state. At the same time, its blades adopt a flexible blade design, which can minimize the friction resistance of the air in the exhaust chamber and reduce the energy consumption of the blades to resist turbulence. When the impeller blades are at a low speed, the turbulent exhaust still has good efficiency.

The blower is equipped with a high-speed permanent magnet synchronous motor, which is driven by a special inverter, and the actual power under different working conditions is different. The air suspension bearing is an important component of the fan. When the fan is running, the suspension bearing generates electromagnetic force to support the rotor to suspend stably. There is no mechanical friction with the surroundings. It has the characteristics of low vibration, low noise, no lubrication and easy maintenance.

In addition, the air suspension blower has a built-in self-developed high-speed frequency converter. The starting current of the blower is about 10A, which has no impact on the power grid. During the operation of the blower, the motor speed is adjusted by the frequency converter to ensure that the fan flow is continuously adjustable within the designed working range. At the same time, it also has a built-in low-pressure pneumatic vent valve controlled by the solenoid valve linkage. The vent valve opening pressure is about 5kPa, and the pneumatic vent valve is opened by the blower outlet pressure.

In terms of performance, the air suspension blower has the characteristics of a wide flow range (9m³/min-324m³/min), large motor power (20HP-400HP 15kw-300kw), and high pressure (20kpa-120kpa). Its application fields are wide, including sewage treatment, food and medicine, textile printing and dyeing, gas transportation, steel galvanizing and other industries. In these fields, air suspension blowers can provide sufficient air flow to maintain the stability of the process, while its low noise and environmental protection characteristics also improve the working environment.

In general, air suspension blowers have become a highly anticipated product in the market with their advanced technology, efficient performance and wide application fields. For more information about air suspension blowers, it is recommended that you contact us directly at 13964080498.
